DongGuan TongToo Aluminum Products Co., Ltd. is a company specializing in aluminum alloy CNC precision machining, injection molding, mold development, and metal parts manufacturing. It has obtained ISO 9001 international certification and strictly implements the 6S management system. With the introduction of German imported equipment, its products are exported to more than 20 countries including Europe, America, and Southeast Asia, with an average annual delivery volume of more than 5 million pieces. With exquisite craftsmanship, fast response, and full-process quality inspection as the core, we provide customized ODM/OEM solutions for global customers and strive to become a trusted strategic partner in the field of international industrial manufacturing.

1.Product Introduction

Dongguan TongToo Aluminum Products Co., Ltd. focuses on the die extrusion production and CNC precision machining of aviation-grade aluminum alloy frame structural profiles. It uses 7075-T6, 2024-T3 and other aviation aluminum materials. Through the independently developed mold design system and CNC machining center, it provides a full-process solution from profile extrusion → heat treatment → finishing → surface treatment. The products are widely used in key parts such as aircraft fuselage frames, satellite bearing structures, and drone skeletons, helping to make aviation equipment lightweight and high-performance.

2.Product Parameter

3.Product Feature And Application

Aviation grade aluminum: 7075-T6 (tensile strength ≥570MPa), 2024-T3 (excellent fatigue performance)

Precision extrusion molding:

Mold life ≥50 tons (H13 steel + surface nitriding treatment)

Profile section tolerance ±0.1mm, straightness ≤0.3mm/m

CNC finishing support: four-axis and five-axis linkage processing of complex connection holes/curved surfaces, position accuracy ±0.02mm

Structural performance guarantee

Lightweight design: multi-cavity topology optimization structure, 40%-60% lighter than traditional steel components

High strength ratio: yield strength ≥450MPa (7075 alloy) after T6 aging treatment

Application

Fixed-wing aircraft

Component types: fuselage keel beam, wing rib frame, door rail

Process adaptation: large-size profile segmented extrusion + high-precision splicing processing

Rotor aircraft

Component types: helicopter main load-bearing frame, rotor hub connector

Process adaptation: special-section profile + titanium alloy insert composite processing

Spacecraft and satellite

Component types: satellite truss, rocket fuel tank bracket

Process adaptation: ultra-thin wall profile (0.8mm thick) anti-deformation processing

UAV system

Component types: folding arm, optoelectronic pod frame

Process adaptation: hollow weight-reducing profile + hard oxidation treatment

Ground support equipment

Component types: aviation ground support bracket, simulator frame

Process adaptation: low-cost 6000 series aluminum profile solution

4.Product Details

Support non-standard cross-section profile development (minimum inner diameter Φ3mm)

Provide one-stop processing of extrusion + CNC + oxidation

Quick mold opening in 15 days (first sample delivery cycle ≤30 days)

5.Product Qualification

Raw material traceability: Provide material certification for each batch of aluminum.

Final inspection items: Three-dimensional measurement full-size inspection.

Salt spray test (aviation grade ≥1000 hours without corrosion).

Ensure compliance with ISO 9001 standards.

Surface treatment: Meet RoHS pollution-free standards.

6.Deliver, Shipping and Serving

Packing solution: Pearl cotton + carton/wooden box.

7. FAQ

Q: What is the minimum wall thickness of profile extrusion?

A: The wall thickness of conventional aviation profiles is 1.5-8mm, and the ultra-thin profile can be 0.8mm (requires reinforcement rib design).

Q: Can conductive oxidation or insulation treatment be provided?

A: Support:

Conductive oxidation (surface resistance ≤ 0.1Ω/sq)

Anodized insulation (voltage resistance ≥ 500V)

Q: How to calculate the cost of profile mold opening?

A: The quotation is graded according to the complexity of the section and the life of the mold. Please consult customer service for the specific cost.

Company Introduction

Our 5000㎡ workshop is equipped with hundreds of production equipment, including German Hammer five-axis CNC machining center (machining accuracy up to 0.002 MM), turning and milling composite CNC lathe, CNC lathe, milling machine, lathe, grinder, etc.; as well as more than a dozen various inspection equipment (including German Cai's three-dimensional, with inspection accuracy up to 0.001MM), and the machining capacity has reached the international advanced level. The Tengtu team has the most professional mold design and CNC machining knowledge. We will work closely with you during the prototyping, production, assembly, inspection, packaging and final delivery process to exceed your expectations.

Our team uses CNC machining to manufacture high-performance parts that support industries such as aerospace, automotive, military, medical, machinery, electronics, and communications. We are committed to innovation and manufacture and assemble important components with excellent precision, strict tolerances and high-quality materials. Over the past 11 years, Tengtu has established a high reputation for efficiency, quality, reliability and on-time delivery.
