DongGuan TongToo Aluminum Products Co., Ltd. is a company specializing in aluminum alloy CNC precision machining, injection molding, mold development, and metal parts manufacturing. It has obtained ISO 9001 international certification and strictly implements the 6S management system. With the introduction of German imported equipment, its products are exported to more than 20 countries including Europe, America, and Southeast Asia, with an average annual delivery volume of more than 5 million pieces. With exquisite craftsmanship, fast response, and full-process quality inspection as the core, we provide customized ODM/OEM solutions for global customers and strive to become a trusted strategic partner in the field of international industrial manufacturing.

Product Introduction

Dongguan Tongtoo Aluminum Products Co., Ltd. focuses on the full process customization of aluminum profiles from 0 to 1: providing one-stop service of extrusion die design and development → profile extrusion molding → precision deep processing → surface treatment → finished product assembly. We rely on mold flow simulation technology, 2000T large-scale extrusion line, fully automatic CNC deep processing center and industry-specific process database to overcome the mass production difficulties of profiles with complex cross-sections, thin-walled multi-cavities and high tolerance requirements, and achieve the industrial-level delivery capability of "one mold molding, precision manufacturing", helping customers break through the bottleneck of structural design and reduce costs and increase efficiency.

Product Parameter

Product Name Customization and Precision Deep Processing of Aluminum Profile Extrusion Dies

Product Material 6061/6063, etc.

Processing Technology: Mold Opening/Extrusion/CNC Deep Processing

Surface Treatment: Anodizing/Hard Oxidation/Laser Engraving

Product Features: Modular structure, supports personalized opening, size, LOGO customization

Product Feature And Application

Core Advantages and Capabilities Details

1. Customized Mold Development-Precise Matching Design Source

Cross-Section Design Optimization Support-Complex Structural Designs such as Special-Shaped Sections, Multi-Cavity Hollows, Heat Dissipation Slats, Hidden Card Slots, etc., Provide DFM Manufacturability Analysis, Avoid Stress Concentration and Deformation Risks

Mold Simulation Technology-Use HyperXtrude/Flow-3D for Extrusion Channel Simulation, Optimize Metal Flow Rate Balance, Reduce Wall Twisting, Weld Defects

Mold Material Technology-Select H13 High-quality Hot-working Die County Steel, After Vacuum Heat Treatment + Cryogenic Treatment, Lifespan of 15-30 Tons/Mold, Support Nano Coating Enhance wear resistance

Quick mold trial response - 15-25 days to open the mold (depending on the complexity), provide trial extrusion samples + test reports, support mold iteration optimization

2. Deep processing of profiles - precision and efficiency dual drive

CNC precision machining - five-axis linkage machining installation holes, end milling, special notches, curved surface modeling, positioning accuracy ±0.05mm, suitable for 6-meter long material one-piece processing

Stamping/hydraulic forming - realize flanging, riveting, embossing, shutter punching and other features to solve the problem of thin-walled profile deformation

Special cutting - laser cutting (burr-free section), double-head sawing (angle accuracy ±0.1°), CNC tapping and drilling (depth-to-diameter ratio 8:1)

Connection strengthening process - stir friction welding (FSW) to join high-strength profiles, precision argon arc welding to seal the cavity, screw connection/pressure riveting component integration

3. Surface treatment and protection system

Anodizing: film thickness 8-25μm (customizable), provide Silver/black/champagne gold and other colors, enhanced corrosion resistance

Powder coating: Fluorocarbon (PVDF)/epoxy polyester coating, weather resistance up to 3000h salt spray test, RAL color cards are all available

Conductive oxidation: Meet EMI electromagnetic shielding requirements, resistivity <0.1Ω/cm²

Sandblasting and brushing: 80-400 mesh sand molds are available to achieve metal matte texture or hair texture

Extreme manufacturing and complex structure control capabilities:

Customization of aluminum profile extrusion dies and precision deep processing product application scenarios:

New energy field

Photovoltaic system: Photovoltaic frame (anti-PID oxidation process), solar tracking bracket (high-strength 6005-T6 profile)

Energy storage equipment: Battery pack shell (IP67 sealing structure), PACK box frame (fireproof coating profile)

High-end industrial automation

Equipment frame: Assembly line conveyor rail (wear-resistant coating), robot protection fence (quick-release structure design)

Functional module: Linear module base (high-rigidity profile), pneumatic slide housing (integrated air path groove)

Lightweight transportation

Rail transportation: subway interior handrails (round tube special-shaped processing), car skirts (large-section stretched profiles

Automotive parts: battery bracket (multi-cavity anti-collision structure), luggage rack rails (mirror polishing process)

Smart buildings and homes

Curtain wall system: unit curtain wall keel (multi-cavity insulation structure), sunshade shutters (deep processing of linkage mechanism)

High-end home: all-aluminum cabinet frame (invisible connector), system doors and windows (glue-injected insulation and thermal insulation profiles)

Product Details

Strict quality control system

Mold detection: 3D scanning and comparison of design drawings (accuracy +0.02mm)

Full profile inspection: cross-sectional dimensions (caliper/projector), wall thickness difference (ultrasonic thickness gauge), straightness (laser detection) 1V

Processing control: first piece FAI report + online CCD dimension monitoring + three-coordinate (CMM) sampling

Performance test: hardness (Webster hardness tester), film thickness (eddy current thickness gauge), adhesion (grid test)

Rich material selection and experience:

Proficient in processing a variety of common and special aluminum alloys, understand the mechanical properties (strength, hardness, ductility) and processing characteristics of different grades (such as 6061-T6, 7075-T651, 5052-H32). Can recommend the most suitable material according to the application scenario (such as lightweight, high strength, corrosion resistance, thermal/electrical conductivity).

Product Qualification

Environmental certification:

RoHS certification (lead-free, cadmium-free and other harmful substances)

REACH (EU Chemical Safety Standard)

Quality Management System:

ISO 9001:2016/ISO 9001:2015 (production process quality control)

Deliver, Shipping And Serving

Professional ODM & OEM manufacturer, with more than 20 years of precision machining experience, based on customer needs, providing a full range of customized services.

Standard packaging: copy paper + carton

Customized packaging: blister tray/PEP + wooden box

Packing solution: pearl cotton + carton/wooden box.

FAQ

Q: What challenging aluminum alloy features are you best at processing (such as thin walls, deep cavities, microstructures)?

A: We specialize in stable processing of ultra-thin walls (<0.8mm), precision holes/cavities with large depth-to-diameter ratios (>10:1), and manufacturing of micro-channels/heat dissipation teeth. We ensure success rate and quality through special tools, process parameter optimization and process monitoring.

Q1: What is the minimum order quantity (MOQ)?

A: We offer flexible order models. For CNC processing and sheet metal processing, we support small batch prototyping (even single pieces) to large batch production. Die casting processing usually requires a certain minimum order quantity. The specific MOQ depends on the complexity of the parts, process requirements and materials. Welcome to consult, we will provide the most cost-effective solution.

Q2: Is the mold opening fee high? Is it cost-effective to order small batches?

A: We use modular mold design to reduce initial costs; support module sharing (only change the mold core). Small batch orders can be diluted by combining molds (one mold with multiple holes), usually ≥500 kg The mold opening fee can be shared, and there is no mold fee for subsequent orders.

Q3: How to choose the surface treatment? Which one is best for my product?

A: The choice of surface treatment depends on your specific needs:

Wear resistance, corrosion resistance, insulation, beautiful coloring: Anodizing (ordinary or hard) is recommended.

High corrosion resistance, uniform coating, complex shape coverage: Electrophoretic coating (ED) is a good choice.

Rich colors, good protection, cost-effective: Powder spraying is applicable.

Matt texture, cover scratches: Sandblasting or brushing.

Conductivity or electromagnetic shielding is required: Conductive oxidation.

Our engineers can recommend the most suitable surface treatment process for you based on your application environment (indoor/outdoor, contact medium, wear resistance requirements, etc.) and appearance requirements.

Q4: Will deep processing cause deformation of the profile? How to control it?

A: Use stress release process + multi-point flexible fixture + layered cutting strategy Triple control:

After extrusion, aging treatment eliminates internal stress

During CNC processing, dynamic compensation deformation

Thin-walled parts use vacuum adsorption clamping

Final deformation ≤0.1mm/m (far exceeding the national standard)

Q5: Can assembly holes be directly processed on the profile surface?

A: Support "extrusion + processing" integrated molding:

Preset process holes: Reserve positioning reference holes during extrusion to improve deep processing accuracy

Feature integration: Embed guide grooves and install bosses during mold design to reduce post-processing

Q6: How to ensure wall thickness uniformity for complex cross-section profiles?

A: Core technology guarantee:

Mold diversion design: Multi-stage welding chamber balances metal flow

Online quenching system: Accurately control the fan water cooling strength to prevent thin wall overburning

Traction machine closed-loop control: Real-time adjustment of tension to eliminate bamboo marks Wall thickness tolerance stable control within ±0.08mm

Company Introduction

Our 5000㎡ workshop is equipped with hundreds of production equipment, including German Hammer five-axis CNC machining center (machining accuracy up to 0.002 MM), turning and milling composite CNC lathe, CNC lathe, milling machine, lathe, grinder, etc.; as well as more than a dozen various inspection equipment (including German Cai's three-dimensional, with inspection accuracy up to 0.001MM), and the machining capacity has reached the international advanced level. The Tengtu team has the most professional mold design and CNC machining knowledge. We will work closely with you during the prototyping, production, assembly, inspection, packaging and final delivery process to exceed your expectations.

Our team uses CNC machining to manufacture high-performance parts that support industries such as aerospace, automotive, military, medical, machinery, electronics, and communications. We are committed to innovation and manufacture and assemble important components with excellent precision, strict tolerances and high-quality materials. Over the past 11 years, Tengtu has established a high reputation for efficiency, quality, reliability and on-time delivery.
